THIRUPATHI INDUSTRIES

Facilities

Home > Facilities

Shearing

  • Ganesh Make - 8mm x 2400 – 1 No
  • Ambika Make - 4mm x 2000 – 1 No

Press Brake

  • Ganesh Make – 8oTon – 3Mtrs – 1 No

Hydraulic Presses

  • 150Ton – 1 No
  • 100Ton - 1 No
  • 50Ton - 1 Nos

De - Coilers

  • AIDA Make – 0.60mm -2.5mm/250mm/1.5Tons
  • Demaco/Hertz - 0.60mm -4mm/400mm/4Tons
  • Demaco/Hertz - 0.60mm -3mm/300mm/3Tons
  • Rattan - 0.60mm -3mm/400mm/3Tons
  • AIDA Make - 0.60mm -2.3mm/300mm/2.5Tons
  • Dimach/ - 0.60mm -2.0mm/150mm/500Kg
  • AIDA Make – 0.60mm -2.5mm/250mm/1.5Tons
  • Demaco 0.6mm - 2.0mm/150mm /300Kg
  • AIDA Make leveler feeder 0.3mm-2.3mm/300mm/2.0Tons x 2 No's

Tube - Machineries

  • Tube Cutting Machine – 2No – Servo Feed -110mm
  • Tube – Semi Automatic Cutting Machine – 01 No's
  • Tube Chamfering -SPM
  • Tube Bending – YLM – 4 Axis /2 Stacker -50mm - 2 No's
  • Tube Polishing SPM – 3 No's

Rod/Wire - Machineries

  • 7 Axis 3D Wire Bending – SARA - 01 No's

Welding Facilities

  • Panasonic Robot – 6 Kgms Payload – 1.4 Mtrs – 5 No's
  • CRP Robot - 6Kgms Payload - 1.4 Mtrs - 1 No's
  • Yaskawa Robot - 6Kgms Payload - 1.4 Mtrs - 1 No's
  • ROTMETA Robot - 10Kgms Payload - 1.4 Mtrs - 2 No's
  • GMAW – Power Source – Panasonic/Lincoln - 16 No's (200-400 Amps)
  • Linear Welding – GMAW – SPM – 1 No's
  • Rotary Welding – GMAW – SPM – 2 No's
  • Multi – Torch – GMAW – SPM – 1 No's

Resistance Welding ( Spot & Projection)

  • Nash/Pacific – 50 Kva – 6 No's (Spot/Projection)
  • 75 Kva Nash/Pacific with Amada/Miyachi Controller – 14 No's
  • 100 Kva Nash – 2 No's
  • Multi Spot Welding – SPM – 2 No's

Nut Feeders

  • M6 - 5 Nos
  • M8- 2 Nos
  • M5- 1 Nos

Electric Overhead Travelling Cranes

  • 15/5 Ton EOT – Electromech – 1No
  • 10Ton EOT – Virali /Craftsman -1 No
  • 7 Ton EOT – Murugan Cranes – 1 No

Surface Finish Machinery

  • Tube OD - Surface Finish - SPM – 3No – Grind Master
  • Buffing Spindles – 4 No's
  • Barrelling Machine – 30 Kgms
  • Semi – Auto Feed - Linishing Machine – 1 No – Grind Master
  • Linishing Machine – 1 No

Captive Power

  • 250Kva Diesel Generator – Kirloskar – 1No's
  • 125Kva Diesel Generator – Kirloskar – 2No's
  • 82.5Kva Diesel Generator – Kirloskar – 1No's
  • 58.5Kva Diesel Generator – Kirloskar – 2No's
  • 30Kva Diesel Generator – Kirloskar – 1 No

Tool Room Facilities

  • Radial Drilling Machine – 1 ½”
  • Drilling Machine – 1 ¼”
  • Drilling Machine - ¾”
  • Tapping Machine - ½”
  • Lathe 4’ – 4 No's
  • Surface Grinding Machine 150mm x 450mm
  • Surface Grinding Machine 200mm x 450mm - Auto Cross Feed
  • Surface Grinding Machine 400mm x 800mm - Auto Cross Feed

Hand Tools & Other Machinery

  • Drilling Machines – 1" – 4Nos
  • Tapping Machine - 1/2" – 4Nos
  • AG4 – 5Nos
  • AG6 – 1No
  • Bench Grinding – 3Nos
  • Air Grinding – 2Nos
  • Air Torque Gun – 3Nos
  • Hand Drilling – 1/2" – 2 Nos
  • Portable Arc Welding Machine -3Nos
  • Segregator – Custom Build
List of Machineries – Power Press
Cross Shaft Press -250Ton – 2.4Mtrs - Double Crank 01 No's
Cross Shaft – Pneumatic Press -200Ton 03 No's
Cross Shaft - Pneumatic Press -160Ton 03 No's
Cross Shaft - Pneumatic Press -125Ton 05 No's
Cross Shaft - Pneumatic Press -100Ton 04 No's
Cross Shaft - Pneumatic Press -80Ton 10 No's
Cross Shaft - Pneumatic Press -63Ton 08 No's
Cross Shaft - Pneumatic Press -50Ton 10 No's
Cross Shaft - Pneumatic Press -40Ton 17 No's
Cross Shaft - Pneumatic Press -25Ton 01 No's
Mechanical Press -250Ton 01 No's
Mechanical Press -63Ton 03 No's
Mechanical Press -50Ton 05 No's
Mechanical Press -40Ton 05 No's
Coil Feeder - 08 No's
Hydraulic Press -150Ton 01 No's
Hydraulic Press -100Ton 01 No's
Hydraulic Press -75Ton 01 No's
Total 88 No's
List of Machineries – Fabrication
Robot - MIG Welding 09 No's
SPM – Linear Welding 01 No's
SPM – Rotary Welding 03 No's
SPM – Spot Welding 02 No's
Spot & Projection Welding – 100KVA 02 No's
Spot & Projection Welding – 75KVA 14 No's
Spot & Projection Welding – 50KVA 06 No's
Nut Feeders M8 ,M6 & M5 08 No's
Conventional MIG Welding 18 No's
Total 63 No's
List of Machineries – Tubular Parts
CNC Tube Cutting SPM 02 No's
CNC Tube Bending - YLM 02 No's
SPM – Grind master 03 No's
SPM – Tube Chamfering Machine 01 No's
Total 8 No's
List of Machineries – Rod/Wire
7 Axis 3D Wire Bending - SARA 01 No's

We have adequate Handling Equipments

2.50Ton Hand Pallet Truck – 06 No's
1.50Ton Semi Electric Stacker – 05 No's
1Ton Hydraulic Hand Stacker – 05 No's
1.5Ton Capacity Electric Stacker-Toyota Make
1.5 T capacity Electric stacker - Nichiyu Make.
